The RT-S52SV rigging tower is the ideal solution for medium to large scale events where flexibility counts, including festivals, concerts, or other major public events. After the system is levelled and ballast is applied, the load can be hoisted into position. The mast should be stabilised by means of the braces, which fix to the legs. After the base is placed, the mast can be built and erected using the hinges on the base corner.

The legs of the V-shaped base can be levelled by means of screw jacks, which are attached to the side of the legs. The RT-S52SV is based on S52SV truss with stabilisers of H30D truss. The medium-to-heavy-duty RT-S52SV has a loading capacity of 1400 to 2900 kg and a maximum lifting height of 12,95 m (please refer to the technical specifications table for further details).

H40D-C016-TRIANGLE 40 4-WAY CORNER CROSS.

H40D-C018-TRIANGLE 40 3-WAY T-JOINT VERT.

H40D-C021-TRIANGLE 40 5-WAY CORNER VERT.

Triangular Corners AstraLite / AstraLive.

Book corners are not designed as load bearing component, loads should be supported at both sides of the corner. Once the correct angle is determined, the book corner can be fixed by using the fixing arm.

ACC-LP-20-60 Locking Pin for CCS7-HINGEīook corners are used to create flexible angles using a hinged connection, any angle can be achieved.ACC-LP-30-D75 Locking Pin 30mm for D75 Truss.ACC-LP-RS-6X120 R-Spring 6 x 120mm for 36mm Pin.AO3-HP Hanging Pack with CS2 + Wedge Skts.TT3-2629223 Push up Electrical Straight Coupler.

TT3-2632290 Push up Electrical Corner Coupler.Total loading 250 kg including 50kg for the ballast, 100kg for the spot and 100kg for the technician. The round mounting ring allows a fully adjustable spot position. The adjustable leg rest and integrated ballast tray and spigot point for the spot make it easy to install. Compact and ergonomic follow spot chair, offering maximum comfort and safety for the technician.
